Bucyrus guidelines for hydraulic hoses

BUCYRUS has issued a set of best practices for high-pressure hose maintenance to help reduce downtime and improve safety.
Bucyrus guidelines for hydraulic hoses Bucyrus guidelines for hydraulic hoses Bucyrus guidelines for hydraulic hoses Bucyrus guidelines for hydraulic hoses Bucyrus guidelines for hydraulic hoses

Greg Rowan, senior inspector of mines, Queensland Government Natural
Resources & Mines

Blair Price

Serious injuries can be caused from even a pin-prick hole in hydraulic hoses, where a powerful jet of fluid can penetrate skin and flesh.

Bucyrus says high-pressure hoses in longwall systems are subject to high operating design pressures, pulsations from pumping systems, impulse from normal shield operation, and potential damage from environmental conditions.

Removal and installation of hoses presents further risk of damage, with Bucyrus saying hose ends are commonly packed with dust and corrosion, which makes removal and replacement difficult.

“Hammers, punches and chisels used to force fittings together can cause tiny cracks in the hose ferrule which, over time, may propagate along the entire length of the ferrule, leading to a catastrophic failure of the hose assembly,” Bucyrus said.

The original equipment manufacturer has consequently released the following best maintenance practices for high-pressure hoses.

  • Always make sure any hose being worked on has been hydraulically isolated from the supply or return system, and residual pressure has been relieved, before starting work.
  • After removing the retaining staple, never “bump” the hose with pressure to cause it to blow itself out. Bumping can result in injury.
  • Always use the exact diameter, length and working pressure rating hose for all replacements. Otherwise premature hose damage and failure may occur.
  • Use of penetrating oil to loosen fittings should be done so sparingly and only after checking with the soluble oil supplier to ensure there will not be any adverse reactions with the emulsion.
  • During longwall moves, the end of the hose removed from a neighbouring shield should be looped around and inserted into the manifold of the shield being moved, to prevent dirt from entering the hoses or contaminating the hose ends. If not possible, cover the exposed hose ends and tie them up to prevent contamination.
  • Before inserting hose ends into manifolds or fittings, make sure all o-rings and backing rings are intact and in good condition. Always clean the hose end before reinserting it.
  • Moly-disulfide (anti-seize compounds) may be applied to the outside of hose ends to make future removal easier. However, never allow these compounds to enter the inside of the hose or any other fittings. They can plug filters throughout the system and cause significant operational problems.
  • Channel lock pliers can be applied to the fitting body (not the ferrule) to attempt to loosen the fitting by twisting it back and forth.
  • If impact is absolutely necessary to loosen or reinstall a fitting, never strike the crimped-on ferrule and never use a chisel of any kind as the contact tool. This will cause an immediate stress riser, which can develop into a crack and ultimately lead to a hose end failure. Only a brass punch or very mild steel rod (

There have been two fatalities involving hydraulics in New South Wales longwall mines in the past eight years.

While NSW has the MDG41 guidelines for fluid power safety, Queensland mine safety authorities prefer to take a more site-based risk approach.
